Description
66-27-135 PTO – Nissan MLS61A/B (UD70 / UD80 / UD90)
| Specification | Value |
|---|---|
| Part Number | 66-27-135 |
| Type | Pneumatic PTO (Power Take-Off) |
| Transmission Compatibility | Nissan MLS61A, MLS61B, MLS62A, MLS62B, MLS63B |
| Vehicle Application | Nissan UD70, UD80, UD90 Series |
| Mounting Position | Left Side Mounting |
| Output Type | Rear Shaft Output |
| Rotation | Anticlockwise (viewed from output shaft) |
| PTO Ratio | 0.595 : 1 to 0.638 : 1 (depending on gearbox version) |
| Maximum Torque | 200 Nm continuous / gearbox-limited rating |
| Weight | Approximately 12.5 kg |
| Shift Type | Pneumatic (Air Operated) |
| Mounting Kit | 154-3-4525 Stud Kit |
Suitable Vehicles
- Nissan UD70
- Nissan UD80
- Nissan UD90
- Nissan PKB214 Series
- Vehicles equipped with MLS61A/B, MLS62A/B, MLS63B transmissions
Typical Applications
- Tipper trucks
- Crane trucks
- Hooklift systems
- Refuse compactors
- Hydraulic pump drives
Associated Components
- Stud Kit: 154-3-4525
- Suitable for UNI, ISO adapter, flange, or shaft output configurations depending on installation requirements.
Note: Some aftermarket versions for the same MLS61A/B transmission family are available with higher torque ratings (up to approximately 475 Nm), but the OMFB 66-27-135 specification is rated at 200 Nm due to transmission gear limitations.
